Specifications
Power Source 220-240 V AC, 50/60 Hz
Power Consumption 30 W
Frequency Response 20 Hz - 20 kHz, ±1 dB
Sampling Frequency 48 kHz
Dynamic Range 100 dB or more
Distortion 0.03 % or less, 1 kHz, +4 dB(*2) input/output, 20 Hz - 20 kHz BPF
Crosstalk -80 dB or less, 1 kHz
Input Monaural input, 8 channels, removable terminal block (3P)
Phantom power (+24 V DC, 10 mA, ON/OFF switchable for each channel)
Gain setting (settable for each channel)
:PAD ON Gain min., +4 dB(*2) (max. +24 dB(*2)), 10 kΩ, electronically-balanced
Gain max., -14 dB(*2) (max. +6 dB(*2)), 10 kΩ, electronically-balanced
:PAD OFF Gain min., -10 dB(*2) (max. +10 dB(*2)), 7 kΩ, electronically-balanced
Gain max., -56 dB(*2) (max. -36 dB(*2)), 7 kΩ, electronically-balanced
Stereo Input (L, R), 7 channels (1-A, 1-B, 1-C, 2-A, 2-B, 2-C, front-mounted input)
RCA jack (stereo mini jack provided on the front panel)
: -10 dB(*2) (max. +10 dB(*2)), 10 kΩ
" Trim gain for each individual channel: - to 0 dB (except front-mounted input)
※ 1-A (L), 1-B (L), and 1-C (L) are mixed after passing through each trim gain circuit
(the same applies to R channel)
※ 2-A (L), 2-B (L), and 2-C (L) are mixed with front-mounted input after passing
" through each trim gain circuit (the same applies to R channel)
Output Output, 4 channels, +4 dB(*2) (max. +24 dB(*2)), applicable load 600 Ω or more,
electronically-balanced, removable terminal block (3P)
REC OUT (L, R): -10 dB(*2) (max. +10 dB(*2)), applicable load 1 kΩ or more, RCA jack
Gain is adjustable.
AD Converter 24 bits
DA Converter 24 bits
Preset Memory 16
