Specifications
System
Type of System UHF Frequency Agile Diversity
RF Carrier Frequency Range Band A – 648 – 676MHz (TV Channels 43 – 48)
Approx. Working Range 300′
Overall Frequency Response 50 – 15kHz +/- 2dB
Signal-to-Noise Ratio > 100dB (A)
# Of Channels 1,112 – programmable in 25kHz steps across 24MHz bandwidth
# Of Simultaneous Systems 16 – for additional consult with EV about custom programmed frequency groups
Receiver
Type of Receiver Synthesized PLL Agile UHF
Type of Outputs Balanced: 3-pin XLR – mic level
Unbalanced: 1/4″ Phone – adjustable line level
Headphone Monitoring No
Power Requirements 12V AC/DC 300mA
Battery Type/Approx. Life AC powered only
Display Backlit LCD
Mounting Options Rack Mountable
Antenna Type Detachable 1/4 wave
Dimensions 1.72 x 7.50 x 5.90″ (43.69 x 190.50 x 150.00mm) (H x W x D)
Weight not specified by manufacturer
Handheld Transmitter
Antennas Internal 1/2 wave
Mic Type Handheld
Power Requireme 9V Battery
Wired/Wireless Wireless
Finish Non-reflecting Black
Case Material High-Impact ABS Plastic
Dimensions (Height X Max Diameter) 240 x 52 mm (9.45 in. x 2.05 in.)
Microphone Applications Female Vocal, Jazz, Male Vocal, Rock, Speech
