Specification
Power Source AC mains, 50/60 Hz (supplied from the included AC adapter)
Power Consumption 15 W or less
Receiving Frequency Channel A: 3.100 MHz Channel B: 3.350 MHz
Receiver Sensitivity Signal to Noise Ratio: 50 dB or more
(40 dBμV input, 1 kHz modulation, ±4.8 kHz deviation)
Signal to Noise Ratio 61 dB or more (60 dBμV input, ±4.8 kHz deviation, A-weighted)
Tone Squelch Frequency 32.768 kHz
Infrared Receiver Input 75 Ω, BNC jack × 2 (Infrared wireless receiver's power source: 24 V DC,
220 mA max. in total of 2 terminals)
Output Channel A and B: -10 dB(*1) (±4.8 kHz deviation, at volume level max.),
600 Ω, electrical balanced, 3 pole phone jack.
Note: Channel A switchable to mixer output.
Frequency Response 100 Hz - 12 kHz
Operating Temperature -10 ℃ to +50 ℃ (14 ゜F to 122 ゜F)
Operating Humidity 30 % to 85 %RH
Finish Case: ABS resin, black
Dimensions 210 (W) × 44 (H) × 210.9 (D) mm (8.27 × 1.73" × 8.3")"
Weight 630 g (1.39 lb) (unit only)
