Technical

HDMI Compliance

HDMI 2.0b

HDCP Compliance

HDCP 2.2/1.x

Video Bandwidth

594MHz/ 18Gbps

Video Resolution

Up to 4k2k@50/60Hz 4:4:4

Color Depth

24-bit,30-bit,36-it(1080p@60Hz)

24-bit (4K2K@60Hz YCbCr4:4:4)

24-bit,30-bit,36-bit(4K2K@60Hz YCbCr 4:2:2/4:2:0)

Color Space

RGB 4:4:4, YCbCr 4:4:4, YCbCr 4:2:2/4:2:0

HDR

Support HDR, HDR10, HDR10+, HLG, Dolby vision

HDMI Audio Formats

PCM 2.0/5.1/7.1CH, Dolby5.1, DTS5.1, Dolby-TrueHD, DTS-HD

ESD Protection

Human body model—±8kV (Air-gapdischarge) &

± 4kV (Contact discharge)

Connection

Input

1×HDMI Type A (19-pin female)

Output

16×HDMI Type A (19-pin female）

Control

1×SERVICE (Micro USB,Update port）1x DIAL switch [5-pin]

Mechanical

Housing

Metal Enclosure

Silk screen Color

Black

Dimensions

300mm(W) × 100mm(D) × 28mm(H)

Weight

900g

Power Supply

Input: AC100 - 240V50/60Hz,

Output: DC12V/2.5A (US/EU standards, CE/FCC/UL certified)

Power Consumption

12W

Operation

Temperature

0°C~40°C/ 32°F~104°F

Storage Temperature

-20°C~60°C/ -4°F~140°F

Relative Humidity

20~90%RH (non-condensing)
