Video Standard

HD&SD

Video Format

1080p50/59.94/60Hz

1080i50/59.94/60Hz

720p50/59.94/60Hz

576i50Hz

480i59.94Hz

Video Processing

HDMI:YUV4:4:4 10bit,RGB:4:4:4

Video Input

4x HDMI

Video Output

3x HDMI

Audio Input

1x Stereo RCA(L/R)
2x Mono Microphone
De-embeddedDigitalAudio(2CH)

Audio Output

1x Stereo RCA(L/R)
1x Stereo headphone (MiniJack with volume control)
Embedded Digital Audio (2CH)

Embedded Audio Support

Embedded 2-CH digital/analogue audio

Chromakey

----

USK

Lumakey

DSK

----

Picture in Picture

1

Logo Insertion

----

Still Store

----

Effects

FTB,Cut,Wipe with border

Tally Output

1x D-sub 15 pin,dualcolor

Built-in Audio Mixer

Yes

Preview Display

Dual 10.1"LCD

Special Features

----

Streaming Encode

H.264/AVC,Main/HighProfile

Streaming Video Bitrate

Record Only: Up to 16Mbps (1080p50/60)
Stream Only: Up to 10Mbps (1080p50/60)
Rec+Stream:10Mbps (1080p25/30)

Streaming Video Rate Mode

CBR

Streaming Audio Mode

Stereo/Mono

Streaming Audio Bitrate

Stereo:64~384Kbps
Mono:32~192Kbps

Streaming Protocols

TS over TCP/ UDP (unicast & multicase)
RTSP over HTTP/ TCP/ UDP (RTSP Elementary Streaming)
RTMP/ RTMPS Publish)
HLS

Network Interface

1x RJ45 (10/100Mbps Ethernet)

Streaming Recording File Format

H.264

Streaming Storage

SD Card

Recording Storage Medium

SD Card

How to Retrieve Recorded Content

Removable HardDrive, transfer data via USB2.0

Recording Storage File System

NTFS,FAT

Recorded File Format

MP4

Dimension (LxWxH)

493x253x331(monitor'sup)

493 x 253 x 190 (monitor's down)

Weight

16kg

Power

DC12V,83W

Operating Temp. Range

0~40°C
