Video Standard

HD

Video Format

1080i50/59.94/60Hz

720p50/59.94/60Hz

Video Processing

SDI:4:2:2

HDMI:YUV4:2:2 10bit,RGB:4:4:4

Video Input

2x HD-SDI

2x HDMI

Video Output

1x HDMI

Audio Input

1x Stereo RCA(L/R)
2x Mono Microphone
De-embedded Digital Audio(2CH)

Audio Output

1x Stereo RCA(L/R)
1x Stereo headphone (Mini Jack with volume control)
Embedded Digital Audio(2CH)

Embedded Audio Support

Embedded 2-CH digital/ analogue audio

Chromakey

2

USK

1x USK support Chroma Key & Linear/LumaKey

DSK

1 (Logo)

Picture in Picture

1

Logo Insertion

1

Still Store

500

Effects

FTB,Cut,32 Wipe with border

Tally Output

1x D-sub 15pin,dual color

Built-in Audio Mixer

Yes

Preview Display

Dual10.1"LCD

Special Features

Stinger Effect

Streaming Encode

H.264/AVC,Main/HighProfile

Streaming Video Bitrate

Record Only: Up to 16Mbps (1080p50/60)
Stream Only: Up to 10Mbps (1080p50/60)
Rec+Stream: 10Mbps(1080p25/30)

Streaming Video Rate Mode

CBR

Streaming Audio Mode

Stereo/Mono

Streaming Audio Bitrate

Stereo:64~384Kbps
Mono:32~192Kbps

Streaming Protocols

TS over TCP/UDP (unicast & multicase)
RTSP over HTTP/TCP/UDP (RTSP Elementary Streaming)
RTMP/RTMPS(Publish)
HLS

Network Interface

1x RJ45 (10/100Mbps Ethernet)

Streaming Recording File Format

H.264

Streaming Storage

SD Card

Recording Storage Medium

SD Card

How to Retrieve Recorded Content

Removable HardDrive, transfer data via USB2.0

Recording Storage File System

NTFS,FAT

Recorded FileFormat

MP4

Dimension (LxWxH)

493x253x331(monitor'sup)

493 x 253 x 190 (monitor's down)

Weight

16kg

Power

DC12V,83W

Operating Temp.Range

0~40°C
