XY86-ZS-RGK Dimming and RGB Control Panel with Knob
1-channel 0-10V and RGB dimming control, can set 3 different preset brightness and RGB to meet the lighting and color needs of different environments.
Input voltage: Neutral + Phase wire AC220V±10% 50/60Hz
Working frequency: 2.4GHz
Protocol: ZigBee 3.0
Dimming and RGB control circuit: 1 channel
Dimming and RGB output control: 0-10V
Function buttons: 4 buttons, 1 knob
Network organization: ZigBee self-organizing network
Size: 86×86×45mm
Installation: Standard box 86
