Specifications
Active or Passive Active
Frequency Response 73Hz to 22kHz (+/- 3dB)
Power Capacity 60W (240W Peak)
Maximum Sound Pressure Level (SPL) 107dB Average
113dB Peak
Nominal Sensitivity 89dB
Impedance 8 ohms
Crossover 2kHz - 2nd order LF, 2nd order HF
Low Frequency Driver 6.50" ICT Driver
High Frequency Driver None
Enclosure Material ABS
Input Connections Removable locking connector with screwterminals with "loop through" facility
Dimensions BM Hole Cutout Diameter 253mm (9.96")
PI Hole Cutout Diameter 253mm (9.96")
Weight CMS601 BM: 6.50kg (14.33lbs)
CMS601 PI: 4.00kg (8.82lbs)
PI back can: 3.685kg (8.06lbs)
