Specification
Rated Input 6W
Rated impedance 1.7k ohms (6W), 3.3k ohms (3W)
[(6.7k ohms (1.5W), 13k ohms (0.8W): Internal wiring must be changed]
Sensitivity 92dB (1W/1m)
Frequency Response 100 - 12,000Hz
Speaker Component 16cm dynamic cone-type speaker
Dimensions for Fixing Hole Mounting hole; ø200m
Ceiling thickness; Max. 50mm
Speaker Mounting Method Spring catch
Applicable Cables 600V vinyl-insulated cable (1V wire or HIV wire)
Solid copper wire; ø0.8 - ø1.2mm
7-core twisted copper wire; 0.75 - 1.25mm2
Connection Push-in connector (bridging and branch connections possible)
Finish Grile: Fire-resistant, high-impact styrene resin (resin material grade; UL94 V-0 or its equivalent), black
Dimensions 235 (W) × 174 (H) ×106.5 (D)mm
Weight 850g
