TANNOY PowerVS10BP 600W 10" Band-Pass Powered Subwoofer ลำโพง , ตู้ลำโพง , speaker

Specifications

POWERVS 10BP

System Type    Subwoofer-Bandpass

Frequency Response (-3dB) (1)    37Hz - 80Hz

Lowpass Filter A on

Frequency Response (-3dB) (1)    37Hz - 110Hz

Lowpass Filter B on

Frequency Response (-10dB) (1)    32Hz - 80Hz

Lowpass Filter A on

Frequency Response (-10dB) (1)    32Hz - 110Hz

Lowpass Filter B on

Rated Maximum SPL (2)    Average: 118dB

Peak: 124dB

 Driver Complement    250mm (10.00”) high excursion bass driver

Crossover    User Selectable LPF

Distortion    10% Full Power (12.7V)

2nd Harmonic

40Hz: 2.27%

100kHz: 1.79%

3rd Harmonic

40Hz: 0.73%

100kHz: 1.27%

1% Full Power (4V)

2nd Harmonic

40Hz: 0.57%

100kHz: 0.61%

3rd Harmonic

40Hz: 0.47%

100kHz: 1.37%

Construction

Enclosure    50 litre internally braced 15mm (0.62”) MDF bandpass enclosure

Finish    Textured black or white paint with custom colours on request

Connectors    1 x female XLR (input)

1 male XLR (link)

1 x Neutrik Powercon

Controls & Indicators    Level control

Power LED (blue)

Signal LED (green)

Limit LED (red)

Full range / high pass switch (110Hz)

Power switch

Fittings    2 x Port aperture blanking plates to allow the bass ports to be moved to another facia

8 x M10 Flying inserts

2 x recessed carrying handles

Blanking plate for optional VTH pole mount

4 x rubber feet

Dimensions (HxWxD)    355 x 385 x 590mm

(13.98 x 14.37 x 23.23”)

Weight    18kg

(39.6lbs)

Electronics

Maximum signal input for clip    Input attenuator at minimum:

+18dBu

Input attenuator at maximum:

+5dBu

Output noise                                                           -105dB unweighted, referenced to maximum output (22kHz bandwidth)

Efficiency    >90% typically

Damping Factor     400 ref 8 Ohms

Distortion    <0.05% @ 1kHz -3dB output (22kHz bandwidth)

Input Impedance    5.6kOhms  unbalanced

11.2kOhms  balanced

Protection systems

Over Current    Excessive over current causes shutdown

Temperature    Limiters applied

Brownout    Automatic protection & recovery

Mains    Inrush current limiting

Indicators     1x Limit LED

1x Signal LED

1x Power LED

Number of channels    One

System Type     Class D

PSU Specifications

Input Connector    Locking Neutrik Powercon

Voltage Selection     Automatic (115 / 230V, 45 - 65Hz)

Type    High current, high frequency switch mode

Efficiency    >90% typical

Input voltage    100v / 115v / 230v nominal

+/-10%

Mains fuse    External

Fuse type    T10AT

Other features    Automatic soft start
