TANNOY VXP 15Q ลำโพง ACTIVE LOUDSPEAKER ลำโพง , ตู้ลำโพง , speaker

Specifications

POWERVS 15BP

System Type    Subwoofer-Bandpass

Frequency Response (-3dB) (1)    47Hz - 80Hz

Lowpass Filter A on

Frequency Response (-3dB) (1)    47Hz - 110Hz

Lowpass Filter B on

Frequency Response (-10dB) (1)    37Hz - 80Hz

Lowpass Filter A on

Frequency Response (-10dB) (1)    37Hz - 110Hz

Lowpass Filter B on

Rated Maximum SPL (2)    Average: 124dB

Peak: 130dB

 Driver Complement    380mm (15.00”) High excursion bass driver

Crossover    User selectable LPF

Distortion    10% Full Power (15.5V)

2nd Harmonic

40Hz: 0.65%

100kHz: 3.05%

3rd Harmonic

40Hz: 0.67%

100kHz: 0.70%

1% Full Power (4.9V)

2nd Harmonic

40Hz: 0.13%

100kHz: 0.76%

3rd Harmonic

40Hz: 0.30%

100kHz: 0.24%

Construction

Enclosure    100 litre internally braced 15mm (0.62”) birch plywood bandpass enclosure

Finish    Textured black or white paint with custom colours on request

Connectors    1 x female XLR (input)

1 male XLR (link)

1 x Neutrik Powercon

Controls & Indicators    Level control

Power LED (blue)

Signal LED (green)

Limit LED (red)

Full range / high pass switch (110Hz)

Power switch

Fittings    8 x M10 flying inserts

2 x recessed carrying handles

Blanking plate for optional VTH pole mount

4 x rubber feet

Dimensions (HxWxD)    665 x 440 x 440mm

(26.18 x 17.32 x 17.32”)

Weight    30kg

(66lbs)

Electronics

Maximum signal input for clip    Input attenuator at minimum:

+18dBu

Input attenuator at maximum:

+5dBu

Output noise                                                           -105dB unweighted, referenced to maximum output (22kHz bandwidth)

Efficiency    >90% typically

Damping Factor     400 ref 8 Ohms

Distortion    <0.05% @ 1kHz -3dB output (22kHz bandwidth)

Input Impedance    5.6kOhm unbalanced

11.2kOhm  balanced

Protection systems

Over Current    Excessive over current causes shutdown

Temperature    Limiters applied

Brownout    Automatic protection & recovery

Mains    Inrush current limiting

Indicators     1x Limit LED

1x Signal LED

1x Power LED

Number of channels    One

System Type     Class D

PSU Specifications

Input Connector    Locking Neutrik Powercon

Voltage Selection     Automatic (115 / 230V, 45 - 65Hz)

Type    High current, high frequency switch mode

Efficiency    >90% typical

Input voltage    100v / 115v / 230v nominal

+/-10%

Mains fuse    External

Fuse type    T10AT

Other features    Automatic soft start
